K-Quip 16T Multipurpose
K-Quip 16T Multipurpose
K-Quip products are designed to be heavy duty and long wearing. Designed by experienced engineers and fabricated and welded to the highest standard. Before being released for general sale, each product is rigorously tested onsite by real people, working in the industry that the product is designed for.
CALL NOW FOR MORE INFO 📞 0044 7739043235
Key Features:
- The flagship of the K-Quip MP range. Available in 14/16/20 Tonne variants
- Hitch eye:EN16
- Drawbar:250x150x8mm 80mm pivot pin with greased boss sprung
- Body Dims: 16x8 with magic door
- Doors: Double skinned, fixed 6mm inner, 4mm outer
- Crib height: 800mm
- Tipping ram: Twin 12T 3 stage
- Suspension: Ko7 multi leaf
- Axles 10 stud commercial axle 105 KPH Rated
- Brakes 420 x 180 4 wheel air over hydraulic
- Tyres: 560/45/22.5 steel belted radial
- Weight 3800 kg
- Drawbar Coil Sprung
- Lighting: Dynamic LED with side markers
- Integrated ladder
- Ramp prepared
Optional extras:
- Ramps
- ABS Braking
- Strap Boxes
- Roll over cover
Specification for K-Quip 16T Multipurpose
The truck body is very eye-catching & allows us to get our 6T digger in with ease
The truck body is very eye-catching & allows us to get our 6T digger in with ease
Leave a Review
Yes bar the 8T and 20T
Yes
K-Quip holds spares and has two service vans covering the UK and Ireland.
Yes on request.
Yes at an additional cost.
Ask a Question
Videos
-
Description
K-Quip products are designed to be heavy duty and long wearing. Designed by experienced engineers and fabricated and welded to the highest standard. Before being released for general sale, each product is rigorously tested onsite by real people, working in the industry that the product is designed for.
CALL NOW FOR MORE INFO 📞 0044 7739043235
Key Features:- The flagship of the K-Quip MP range. Available in 14/16/20 Tonne variants
- Hitch eye:EN16
- Drawbar:250x150x8mm 80mm pivot pin with greased boss sprung
- Body Dims: 16x8 with magic door
- Doors: Double skinned, fixed 6mm inner, 4mm outer
- Crib height: 800mm
- Tipping ram: Twin 12T 3 stage
- Suspension: Ko7 multi leaf
- Axles 10 stud commercial axle 105 KPH Rated
- Brakes 420 x 180 4 wheel air over hydraulic
- Tyres: 560/45/22.5 steel belted radial
- Weight 3800 kg
- Drawbar Coil Sprung
- Lighting: Dynamic LED with side markers
- Integrated ladder
- Ramp prepared
Optional extras:
- Ramps
- ABS Braking
- Strap Boxes
- Roll over cover
-
Specifications
16T Twin 10 Stud Commercial Axle 16ft 8ft 8mm 560/45/22.5 Steel Belted Radial 800mm Twin 12T 3 Stage 8.3m3 lay flat door | 8.64m3 up and over door -
Reviews
We are currently operating on several wind farm projects. The trailer is certainly earning her keep. Very impressed & highly recommend it.
The truck body is very eye-catching & allows us to get our 6T digger in with ease
The truck body is very eye-catching & allows us to get our 6T digger in with ease
Leave a Review
-
Q&A's
Question: Are the dropsides and Multipurpose trailers ramp prepared with a ramp rail ramp compartment? Answer:Yes bar the 8T and 20T
Question: Do tie hooks come as standard? Answer:Yes
Question: What level of service support will be available? Answer:K-Quip holds spares and has two service vans covering the UK and Ireland.
Question: Can ramps be supplied with the trailers? Answer:Yes on request.
Question: Can you get a different colour than th standard? Answer:Yes at an additional cost.
Ask a Question
-
Attachments
-
Images
-
-
Videos
-
