Fleming Agri 6ft General Purpose Grab

Size ft : 6ft Tines : 17 Item weight : 310kg Item width : 1840mm Item height : 824mm Item depth : 806mm Item capacity : 0.9m3 Item hydraulic rams : 2

Fleming Agri 6ft General Purpose Grab

The Fleming General Purpose Grabs are made to highest standard possible and are a versatile tine grab which is ideal for muck and silage. They are suitable for tractor mounted front end loaders as well as skid steers.

The Fleming General Purpose Grab The General Purpose Grabs are also a very cost effective mode of transportation and are available in 3 sizes 4ft, 5ft and 6ft.

Standard features include:

  • All hinge points are fitted with grease points
  • The top grab has 2 hydraulic cylinders for powerful gripping action and low power requirement
  •  4 curved tines on 4ft and 5 curved tines on 5ft
  • Curved tines are seated in pinched sockets to prevent tine turning during operation.
  • Forged tines mounted in steel bushings
  • Heavy duty box section frame
  • Wear strips fitted on main beam
  • 890mm opening for large payload.
  • Locked pivot pins to prevent excessive wear with easy access grease points.
  • Good ram clearance for smooth operation.
  • 4ft model (SGB4) has 6 tines in base and 2 side tines for secure capacity
  • 5ft model (SGB5) has 8 tines in base and also 2 side tines
  • 6ft model (SGB6) has 2 rams and eleven tines
Fleming Agri 6ft General Purpose Grab

Specification for Fleming Agri 6ft General Purpose Grab

6ft 17 310kg 1840mm 824mm 806mm 0.9m3 2
