Walter Watson 3m x 36" x 14mm Water Ballast Land Roller c/w Rear Hydraulic Wheel Kit

Roller type : Hyd. Lift Land roller laden weight kg : 2250kg Roller unladen weight : 4100kg Roller rolling width : 9ft 8 Roller drum dia : 0.91m Roller wall thickness : 14mm Roller transport width : 3.05m

Walter Watson 3m x 36" x 14mm Water Ballast Land Roller c/w Rear Hydraulic Wheel Kit

The Walter Watson roller frame ends have been designed with 24mm thick plate, this enables barrel ends to be inset to reduce transport width and give greater rolling width.

Key features:

  • Rolling Width – 3.00m
  • Transport Width – 3.05m
  • Barrel Diameter –  36”
  • Barrel Thickness – 10mm – 14mm
  • “Greasable centre support for 3” shaft which enables transportation fully ballasted. Nylon Bush Bearings on all models.”
  • Double Acting Ram c/w Safety Check Valve
  • Axle – 3” Solid Shaft (EN8)
  • Nylon Bush Bearings as Standard
  • Centre Support c/w Greasable Nylon Bush
  • 6 Stud Heavy Duty Axle c/w Greasable Pivot Points
  • High Quality 2 Pack Paint Finish
  • Scraper as Standard
  • Heavy Duty Ring Hitch
Walter Watson 3m x 36" x 14mm Water Ballast Land Roller c/w Rear Hydraulic Wheel Kit

Specification for Walter Watson 3m x 36" x 14mm Water Ballast Land Roller c/w Rear Hydraulic Wheel Kit

Hyd. Lift 2250kg 4100kg 9ft 8 0.91m 14mm 3.05m
This product has no reviews.

Leave a Review

By clicking the Submit button you agree to our T&Cs and Privacy policy

This product has no questions.

Ask a Question

By clicking the Submit button you agree to our T&Cs and Privacy policy

  • Description

    The Walter Watson roller frame ends have been designed with 24mm thick plate, this enables barrel ends to be inset to reduce transport width and give greater rolling width.

    Key features:

    • Rolling Width – 3.00m
    • Transport Width – 3.05m
    • Barrel Diameter –  36”
    • Barrel Thickness – 10mm – 14mm
    • “Greasable centre support for 3” shaft which enables transportation fully ballasted. Nylon Bush Bearings on all models.”
    • Double Acting Ram c/w Safety Check Valve
    • Axle – 3” Solid Shaft (EN8)
    • Nylon Bush Bearings as Standard
    • Centre Support c/w Greasable Nylon Bush
    • 6 Stud Heavy Duty Axle c/w Greasable Pivot Points
    • High Quality 2 Pack Paint Finish
    • Scraper as Standard
    • Heavy Duty Ring Hitch
  • Specifications

    Hyd. Lift 2250kg 4100kg 9ft 8 0.91m 14mm 3.05m
