Walter Watson 3m x 36" x 14mm Water Ballast Land Roller c/w Rear Hydraulic Wheel Kit
Walter Watson 3m x 36" x 14mm Water Ballast Land Roller c/w Rear Hydraulic Wheel Kit
The Walter Watson roller frame ends have been designed with 24mm thick plate, this enables barrel ends to be inset to reduce transport width and give greater rolling width.
Key features:
- Rolling Width – 3.00m
- Transport Width – 3.05m
- Barrel Diameter – 36”
- Barrel Thickness – 10mm – 14mm
- “Greasable centre support for 3” shaft which enables transportation fully ballasted. Nylon Bush Bearings on all models.”
- Double Acting Ram c/w Safety Check Valve
- Axle – 3” Solid Shaft (EN8)
- Nylon Bush Bearings as Standard
- Centre Support c/w Greasable Nylon Bush
- 6 Stud Heavy Duty Axle c/w Greasable Pivot Points
- High Quality 2 Pack Paint Finish
- Scraper as Standard
- Heavy Duty Ring Hitch
Specification for Walter Watson 3m x 36" x 14mm Water Ballast Land Roller c/w Rear Hydraulic Wheel Kit
Hyd. Lift
2250kg
4100kg
9ft 8
0.91m
14mm
3.05m
This product has no reviews.
Leave a Review
This product has no questions.
Ask a Question
-
Description
The Walter Watson roller frame ends have been designed with 24mm thick plate, this enables barrel ends to be inset to reduce transport width and give greater rolling width.
Key features:
- Rolling Width – 3.00m
- Transport Width – 3.05m
- Barrel Diameter – 36”
- Barrel Thickness – 10mm – 14mm
- “Greasable centre support for 3” shaft which enables transportation fully ballasted. Nylon Bush Bearings on all models.”
- Double Acting Ram c/w Safety Check Valve
- Axle – 3” Solid Shaft (EN8)
- Nylon Bush Bearings as Standard
- Centre Support c/w Greasable Nylon Bush
- 6 Stud Heavy Duty Axle c/w Greasable Pivot Points
- High Quality 2 Pack Paint Finish
- Scraper as Standard
- Heavy Duty Ring Hitch
-
Specifications
Hyd. Lift 2250kg 4100kg 9ft 8 0.91m 14mm 3.05m -
